LT1761ES5-5

SOT235, regulator, 20mVRMS

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.86~0.94 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.86~0.94

PartNumber:: LT1761ES5-5

Brand:: Linear Technology - Linear | Pack: SOT | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Jason's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-04-29

From Other Seller

Part Number:LT1761ES5-5
US $0.86 - 0.94
RTL8102EL

US $1.00 - 2.00 / Piece
(0) Remove
P102W

US $15.00 - 22.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT1761ES5-5 is a micropower, low noise, low dropout regulator. With an external 0.01mF bypass capacitor, output noise drops to 20mVRMS over a 10Hz to 100kHz bandwidth. Designed for use in battery-powered systems, the low 20mA quiescent current makes them an ideal choice. In shutdown, quiescent current drops to less than 0.1mA. The devices are capable of operating over an input voltage from 1.8V to 20V, and can supply 100mA of output current with a dropout voltage of 300mV. Quiescent current is well controlled, not rising in dropout as it does with many other regulators.

Parametrics

Absolute maximum ratings: (1)IN Pin Voltage: ±20V; (2)OUT Pin Voltage: ±20V; (3)Input to Output Differential Voltage: ±20V; (4)ADJ Pin Voltage: ±7V; (5)BYP Pin Voltage: ±0.6V; (6)SHDN Pin Voltage: ±20V; (7)Output Short-Circut Duration:Indefinite; (8)Operating Junction Temperature Range: –40℃ to 125℃; (9)Storage Temperature Range: –65℃ to 150℃; (10)Lead Temperature (Soldering, 10 sec): 300℃.

Features

Features: (1)Tiny 5-Lead SOT-23 Package; (2)Low Noise: 20mVRMS (10Hz to 100kHz); (3)Low Quiescent Current: 20mA; (4)Wide Input Voltage Range: 1.8V to 20V; (5)Output Current: 100mA; (6)Very Low Shutdown Current: < 0.1mA; (7)Low Dropout Voltage: 300mV at 100mA; (8)Fixed Output Voltages: 1.5V, 1.8V, 2V, 2.5V, 2.8V, 3V, 3.3V, 5V; (9)Adjustable Output from 1.22V to 20V; (10)Stable with 1mF Output Capacitor; (11)Stable with Aluminum, Tantalum or Ceramic Capacitors; (12)Reverse Battery Protected; (13)No Reverse Current; (14)No Protection Diodes Needed; (15)Overcurrent and Overtemperature Protected.
