Product Summary
The LT3008ETS8-3.3 is a micropower, low dropout voltage (LDO) linear regulator. The devices supply 20mA output current with a dropout voltage of 300mV. No-load quiescent current is 3μA. Ground pin current remains at less than 5% of output current as load increases. In shutdown, quiescent current is less than 1μA.
Parametrics
Absolute maximum ratings: (1)IN Pin Voltage: ±50V; (2)OUT Pin Voltage: ±50V; (3)Input-to-Output Differential Voltage: ±50V; (4)ADJ Pin Voltage: ±50V; (5)SENSE Pin Voltage: ±50V; (6)SHDN Pin Voltage: ±50V; (7)Output Short-Circuit Duration: Indefinite; (8)Operating Junction Temperature Range: –40℃ to 125℃; (9)Storage Temperature Range: –65℃ to 150℃; (10)Lead Temperature: Soldering, 10 sec, TS8 Package Onl: 300℃.
Features
Features: (1)Ultralow Quiescent Current: 3μA; (2)Input Voltage Range: 2.0V to 45V; (3)Output Current: 20mA; (4)Dropout Voltage: 300mV; (5)Adjustable Output (VADJ = VOUT(MIN) = 600mV); (6)Fixed Output Voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V; (7)Output Tolerance: ±2% Over Load, Line and Temperature; (8)Stable with Low ESR, Ceramic Output Capacitors (2.2μF Minimum); (9)Shutdown Current: <1μA; (10)Current Limit Protection; (11)Reverse-Battery Protection; (12)Thermal Limit Protection; (13)TSOT-23 and 2mm × 2mm DFN Packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT3008ETS8-3.3#TRMPBF |
|
IC REG LDO 3.3V 20MA TSOT23-8 |
Data Sheet |
|
|
||||||||||
 |
LT3008ETS8-3.3#TRPBF |
|
IC REG LDO 3.3V 20MA TSOT23-8 |
Data Sheet |
|
|
||||||||||
