The LT1790ACS6-2.5 is a SOT-23 micropower low dropout reference that combines high accuracy and low drift with low power dissipation and small package size. These micropower references use curvature compensation to obtain a low temperature coefficient and trimmed precision thin-film resistors to achieve high output accuracy. In addition, it is post-package trimmed to greatly reduce the temperature coefficient and increase the output accuracy. Output accuracy is further assured by excellent line and load regulation. Special care has been taken to minimize thermally induced hysteresis.
Parametrics
Absolute maximum ratings: (1)Input Voltage: 20V; (2)Specified Temperature Range: Commercial: 0℃ to 70℃; Industrial: –40℃ to 85℃; (3)Output Short-Circuit Duration: Indefinite; (4)Operating Temperature Range: – 40℃ to 125℃; (5)Storage Temperature Range: – 65℃ to 150℃; (6)Lead Temperature (Soldering, 10 sec): 300℃.
Features
Features: (1)High Accuracy; (2)Low Drift; (3)Low Profile (1mm) ThinSOTTM Package; (4)Low Supply Current: 60mA Max; (5)Sinks and Sources Current; (6)Low Dropout Voltage; (7)Guaranteed Operational –40℃ to 125℃; (8)Wide Supply Range to 18V; (9)Available Output Voltage Options: 1.25V, 2.048V, 2.5V, 3V, 3.3V, 4.096V and 5V.
