Product Summary

The LT1790ACS6-4.096 is a SOT-23 micropower low dropout reference that combines high accuracy and low drift with low power dissipation and small package size. It is suitable for handheld instruments, negative voltage references, industrial control systems, data acquistion systems and battery-opterated equipment.

Parametrics

Absolute maximum ratings: (1)Input Voltage: 20V; (2)Specified Temperature: Range Commercial: 0℃ to 70℃; Industrial: –40℃ to 85℃; (3)Output Short-Circuit Duration: Indefinite; (4)Operating Temperature Range: – 40℃ to 125℃; (5)Storage Temperature Range: – 65℃ to 150℃; (6)Lead Temperature (Soldering, 10 sec): 300℃.

Features

Features: (1)High Accuracy; (2)Low Drift; (3)Low Profile (1mm) ThinSOTTM Package; (4)Low Supply Current: 60mA Max; (5)Sinks and Sources Current; (6)Low Dropout Voltage; (7)Guaranteed Operational –40℃ to 125℃; (8)Wide Supply Range to 18V; (9)Available Output Voltage Options: 1.25V, 2.048V, 2.5V, 3V, 3.3V, 4.096V and 5V.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LT1790ACS6-4.096
LT1790ACS6-4.096

Other


Data Sheet

Negotiable
LT1790ACS6-4.096#TR
LT1790ACS6-4.096#TR


IC VREF SERIES 4.096V SOT-23-6

Data Sheet

0-2500: $1.84
LT1790ACS6-4.096#TRM
LT1790ACS6-4.096#TRM


IC VREF SERIES 4.096V SOT-23-6

Data Sheet

0-2500: $1.87
LT1790ACS6-4.096#TRMPBF
LT1790ACS6-4.096#TRMPBF


IC VREF SERIES 4.096V SOT-23-6

Data Sheet

0-1: $4.21
1-25: $3.75
25-100: $3.38
LT1790ACS6-4.096#TRPBF
LT1790ACS6-4.096#TRPBF


IC VREF SERIES 4.096V SOT-23-6

Data Sheet

0-2500: $1.84
